Antares Circulating pumps

ANTARES circulation pump type MODULEX SOLAR with high energy efficiency with frequency modulated inverter and with PWM2 or PWM1 parameterizable control socket, equipped with the AUTO ADAPT self-adjusting function with and without PWM cable connection. Specifically suitable for solar systems.

Max flow rate: m3 / h 3.3. Self-regulating. It satisfies all the needs of the circulator in a single product. Complete with gaskets and power cables. 230 Vac power supply. - 4 year warranty.

P.031

P.032

Circulator with body in composite plastic with incorporated automatic deareator.

Compatible: Wilo FRSL15 / 6 - FERROLI: Domitech, Domiproject, Divatop and others. For the performance curves see Art. P.060.5- and for the modulating model Art. P.110. 230 V 50 Hz - Complete with cables for the modulating model.

P.039

Antares circulation pump with air separator and automatic deaerator. Plastic composite body. Wilo KSL and Grundfos compatible.

For the performance curves see Art. P.060.6- and for the modulating model Art. P.110. 230 V 50 Hz - Complete with cables for the modulating model.

P.060

ANTARES Circulatiepomp Out of stock, see alternative item in the table below

230 V - 50 Hz

P.084

Reservemotor voor circulatiepompen van verschillende merken - Pershoogte 6 m.

Compatibel met circulatienpompen van ´GRUNDFOS´, ´MYSON´, ´ANTARES´, en andere merken met pershoogte tot 6 meter. Compleet met Kit met sluitringen die een eenvoudige installatie op vele pomphuizen toelaat. 3 regelbare snelheden - 230 V.

P.085

Universal spare motor with turbine for the substitution of domestic circulation pumps WILO WSC complete with set of washers and screws Anticlockwise rotation.

Complete with adjustable speed control switch to obtain delivery head of 4/5 and 6 meters 230vac

P.079

High-efficiency circulation pump ANTARES, model “AlfaMega” 40, with DN 40 flanged connections, wet rotor design. Single-phase 230 VAC version, with frequency modulation control. Cast iron pump body, designed for reliable and energy-efficient operation.

With proportional pressure control and constant pressure control functions.

P.080

ANTARES circulation pump type AlfaMega 50-12 flanged DN50 high energy efficiency with wet rotor and PWM control socket. Single-phase 240 Vac frequency modulation - Max flow rate: 31m3 - Max head: 18m

With AUTO ADAPT function, proportional pressure control, constant pressure control, constant flow control. Cast iron body. IP42 protection.

P.081

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

P.082
