BIOMASS

1 2 3 4 5 6 7 8

N.663

Flue fan without shell, motor with external impeller, encoder incorporated thermal protection. Complete of condenser, height of impeller: 33 mm. Diameter of impeller: 180 mm- Diameter of fixing flange: 208 mm - 230 VAC - 50 Hz.

Interchangeable with models: PL30 della l2 Nattalini/Sit - R2E180 della EBM PAPST. Compatible with apparatus: LAMINOX - EDILKAMIN - EVA CALOR - FERROLI - NORDICA - PALAZZETTI - COLA - MCZ - TERMOVANA.

N.669

Pack of 5 gaskets for suction fumes ´Insulfrax´. To be used between shell and motor-plate.

N.670

Pack of 5 siliconic hind washers, red colour, for suction fumes.

R.428

Differential air/gas pressure switch for boilers ´PRESSAIR´ compatible ´HONEYWELL´ C6065.

S.047

Thermal pre-assembled exchange group for the separation of the open circuit from the closed for heating systems through back boilers, fireplaces, biological fuel, compressed wood chippings.

Equipped with stainless steel heat exchanger AISI 304 (Art S.009) 2 pumps in energy class ´A´ (Art P.064.6) 2 ball valves (Art E.465), 2 ball valves with thermometer (Art E.478) and 2 check valves (Art A.010.10) Max working temp. 99°C Max working pressure 15 bar.

E.750

Vachum unit ´NOVA 2´for pellet and biomass fuel suction systems with 2 tubes, suction tube and external air exhaust, with dust and filter separation.

Diam for tubes in PVC 50 - Exit for tubes in PVC exhaust air 50. Electrical feed 230 Vac Motor power KW1.35 air delivery mc/h 234.

E.755

Electronic control panel that allows for automatic functioning of system and its components. Prepared for the wiring and control of all its components. Complete of two leds that show the status of function of the system. Electric feed 230 Vac.

E.780

Vertical motorised extractor ´TALPA´ suitable for exctracting fuel from a hight from deposits with flat base and also from large prefabricated deposits, suitable for exctracting systems with one tube diam 50, the excractor is equipped with an electrical motor with movement propellers for the fuel mass to facilitate grip.

Electrical feed: 230 Vac - Nominal power: W15 - Protection range: IP44 - N. turns rpm 12.

E.782

Squared suction plug complete with tube connection diam 32. This plug allows for the insertion of flex tube (Art. E-808) for cleaning on boiler premisis and ashes. For this it is sufficient to close the fuel tank suction valve (Art. E.783.50) tube PVC conn diam 50.

E.783

Ball valve for tube in PVC diam 50 equipped with microswitch for the exclusion of the suction fuel plant and activation of the cleaning plug.

E.785

Dosage ´DISPENSER´ to be positioned above the pellet tank with which all boilers are equipped. Necessary for the automatic function. Extremely simple to install allows for adaption to all tanks supplied with boilers. Imprinted for drilling and installment. Magnetic switch for signalling unloading of fuel. Tube connection in PVC diam 50.

E.786

Bracket necessary for fixing to the wall dosage ´DISPENSER´-
