Es können bis zu 4 Stellenantriebe auf einem Ausgang verbunden werden. Stromspeisung: 230 VAC - Ausgang Pumpe: 230 VAC 4A.

Suitable for embedded thermostats.

AAdapting plate for embedded box

It is an electronic device of advanced conception that allows to keep under precise control the surrounding enviroment temperature. This control unit acquires temperature data from the probes and adapts the heating fluid to the climatic needs desired, allowing great comfort. Programming is very easy, you just follow the instructions requested setting them straight on the display. This model T.Reg. 300 is a versatile device which allows the operator to choose how it should function connecting it to mixing valves (proportional integral functioning) or burners (ON - OFF function). These technical characteristics make it ideally installable for the control of heating in civil and industrial plants.Constant deisplay of all the system’s elements ; graphic display, back light. Dimensions: 158x90x58x installement on panel on bar Omega EN 50092 with shift buttons for programming and control of temperature coming from probes. Constant visibility of all the temperatures of the heating system. Languages for installement forseen in: English, Italian, Spanish, and French. Daily or weekly clock included; possible programming of temperature desired daily in the week. Possible selection of mode; valve or burner - automatic or manual - off, control of circulating pump, visibility and mode of the performance range. Consult documentation that you can download for more details

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

Schaal: ± 5°C - Afmetingen: 66 x 31 x 89 mm.

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

Art. T.109.40 - Complete with joint for valves Art. E.140 and Art. E.141.

When the temp. of the panels is superior to that of the water in the boiler, the thermostat starts the pump the allows for temp exchange between the panels and the boiler. With clock visability of temp.of collector and boiler.Collector 0°-200°C Feed 230V exit conn. for pump to boiler 5A Dimensions 131x88x(H)27.2 Probes connectabile upto 100mt.

The thermostat SOLAR CONTROL is an electronic device built after many years of experience in the thermal control field by ANTARES. This device allows you to keep a precise control of the temperature deriving from the solar panels and to distribute the hot water into the tank. Through the sensors it will detect the temperature of the water supplied to the tank and it will compare it with the fluids in the solar panel. When the temperature of the panels is higher than the one from the tank, the differential thermostat starts the pump which allows the exchange of heat between panel and tank. To ensure a perfect exchange of temperature the device has a temperature differential “delta T” variable from 1 to 9 °C which is controlled by the handle on the front part of the thermostat. Temperature control : 30-80 °C. Adjustable range : 1-9°C Relay Outlet 10A 230V. Installation DIN bar (3 modules). Dimensions 53x90x58. Probes connected up to 100 mts. Complete with 2 switch-offs: pump for solar panels and pump for circuit integration.
