Antares Relaunch modules

E.609

Special ´T´ joint for condensation alignments for the in/out flow of the mixing valves (T.133.50 E.215. E.143.12).

Terminal poles distance 90mm Connections 11/2´F x 11/2´M x 1´F

E.610

Pair of brass adapters for mounting DN25 1´1/2 M. Pump Groups on manifolds with different outlets.

E.612

Paar 2´ V. afsluitdoppen voor verdeelleidingen Art. E.600 (n. 2 G.150.20).

E.613

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.619

Paar beugels voor bevestiging van verdeelleiding Art. E.600. aan de muur.

Gemaakt uit 2 kragen, zware uitvoering, aanpaspare veer, douwels en vastzettende vijzen.

E.621

Invertable relaunch assembly DN25, composed of 2 ball valves with thermometer and one way valve, high efficency adjustable circulation pump ´Modulex Hybrid´ 6mt delivery, alignment spacer and ball valve with screw-driver adjustment for eventual substitution of pump and isolation shell.

* For power up to 50 KW: predispoded for insertion of by-pass valve for eventual over pump pressure (Art. P.301.03).

E.623

Module DN25 for lowering and regulating thermostatic temperature at fixed point of : 30° - 60°C for systems with radiant panelscomposed of 2 ball valves with thermometer and one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 3 way thermostatic valve, alignment spacer, and ball valve screw-driver adjustable for eventual substitution of pump, safety thermostat manual reset for stopping pump in case of abnormalities and isolating shell.

* predisposed for insertion of by-pass valve for eventual over pump pressure (Art P.301.03).

E.624

Module DN25 for lowering and regulating modulating temperature with separate electronic apparatus (see art. T101). Suitable for systems with high and low temperature (radiators and panels) composed of 2 ball valves with thermometer and one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 3 way motorized mixing valve with by-pass, alignment spacer, and ball valve screw-drive adjustable for eventual substitution of pump, safety thermostat manual rest for stoppi

Predisposed for insertion of by-pass valve for eventual over pump pressure for power up to 38 KW (Art P.301.03) ** For servomotor characteristics see art. T.109.

E.627

Anticondensation preassembled module for heat generators on solid fuel feed, with thermostatic assembly

Complete of circulating pump energy class A ´Modulex Hybrid´ with 6mt delivery, anticondensation by-pass, interception valve, thermometer and check valve, wall fixing brackets. Complete of isolating shell.. Model DN 25 for power upto 32 KW: Connection 1´ - Flow KV: 3,2.

E.628

Anticondensation module for heat generators on solid fuel feed with motorized mixing valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 2 ball valves with thermometer, check valve, alignment spacer and isolating shell

E.629

Thermal exchange module for hydraulic circuits

Prepared for direct connection with anticondensation biomass heat generators (Art E.627 on page..) and also for the control units for the lowering or mixing of temperature for radiant systems. (Art E.623 and E.625 on page..) It is composed of steel plate heat exchanger in the power listed, neccessary preassembled connection fittings and isolating shell. prepared for the connection of various accessories in corrispondence with the four ´T´ fittings - Distance between holes: 125mm.

E.630

Invertable relaunch module DN 32 composed of 2 ball valves with thermometer and integrated one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ with 6mt delivery, ball valve for eventual substitution of pump and isolating shell. Suitable for power upto 125 KW - Connections: 11/4´M and 11/2´ with largening rings included.
