Antares Relaunch modules

ANTARES circulation pump type MODULEX SOLAR with high energy efficiency with frequency modulated inverter and with PWM2 or PWM1 parameterizable control socket, equipped with the AUTO ADAPT self-adjusting function with and without PWM cable connection. Specifically suitable for solar systems.

Max flow rate: m3 / h 3.3. Self-regulating. It satisfies all the needs of the circulator in a single product. Complete with gaskets and power cables. 230 Vac power supply. - 4 year warranty.

T.224

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

T.210

Temperature probe for solar panels Pt 1000Cl. B EN60751.

Sensor in steel tube 6x50mm- Grey silicon cable Length . 1000mm – pre insulated tips. Temperature range -50/+180°C

S.047

Thermal pre-assembled exchange group for the separation of the open circuit from the closed for heating systems through back boilers, fireplaces, biological fuel, compressed wood chippings.

Equipped with stainless steel heat exchanger AISI 304 (Art S.009) 2 pumps in energy class ´A´ (Art P.064.6) 2 ball valves (Art E.465), 2 ball valves with thermometer (Art E.478) and 2 check valves (Art A.010.10) Max working temp. 99°C Max working pressure 15 bar.

E.670

Decoupled circuit separator ´SEPACIR´ with covering sheath. Connections 3/4´ for heating and 1/2´ for feeding circuit.

Composed of the following components - Steel plate heat exchanger XXKWAT - Circulator 6mt in energy class ´A´Expansion vessle inserted or external equipment; - 3 bar safety valveCapillary manometer; -circuit feeding tap; - 4 intercepting ball valves; Dirt separator optional as accessory; automatic deareator; 4 steel flex 3/4´ extendible for connection.

E.640

Pre-assembled module for the supply of hot sanitary water including; brazed plate heat exchanger, 2 ball valves (e.430.10) 1 spacer tube, pumps energy class ´A´ (p.064.6) auto- regulating, 2 ball valves with therm. And check valve (e.478) 2 therm. On sanitary circuit and thermo.isolating shell in polystyrene.

Available with or without 3 way thermostatic mixing valve, for controlling temperature of hot sanitary water. Conn: heating system 1´M - distance 125 - max pressure 10 bar.

E.629

Thermal exchange module for hydraulic circuits

Prepared for direct connection with anticondensation biomass heat generators (Art E.627 on page..) and also for the control units for the lowering or mixing of temperature for radiant systems. (Art E.623 and E.625 on page..) It is composed of steel plate heat exchanger in the power listed, neccessary preassembled connection fittings and isolating shell. prepared for the connection of various accessories in corrispondence with the four ´T´ fittings - Distance between holes: 125mm.

E.438

Module mounted ball valve with pump connection and red pocket handle for thermometer + thermometer . Thermometer scale 0°C-160° C. Check valve and fixing holes.

Pressure max: 10 bari - Temp max : 140°C -Conn. 3/4´ F. x 1´ F. swivel.

E.439

Module mounted ball valve with pump connection side connection 3/4´ F with blue coloured handle pocket thermometer + thermometer. Thermometer scale 0°C-160° C. Check valve, disconnection and passage holes.

Pressure max 10 bar temp- max 140° C conn. 3/4´ F x 1´ F swivel.

E.627

Anticondensation preassembled module for heat generators on solid fuel feed, with thermostatic assembly

Complete of circulating pump energy class A ´Modulex Hybrid´ with 6mt delivery, anticondensation by-pass, interception valve, thermometer and check valve, wall fixing brackets. Complete of isolating shell.. Model DN 25 for power upto 32 KW: Connection 1´ - Flow KV: 3,2.

E.628

Anticondensation module for heat generators on solid fuel feed with motorized mixing valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 2 ball valves with thermometer, check valve, alignment spacer and isolating shell

E.624

Module DN25 for lowering and regulating modulating temperature with separate electronic apparatus (see art. T101). Suitable for systems with high and low temperature (radiators and panels) composed of 2 ball valves with thermometer and one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 3 way motorized mixing valve with by-pass, alignment spacer, and ball valve screw-drive adjustable for eventual substitution of pump, safety thermostat manual rest for stoppi

Predisposed for insertion of by-pass valve for eventual over pump pressure for power up to 38 KW (Art P.301.03) ** For servomotor characteristics see art. T.109.

E.623

Module DN25 for lowering and regulating thermostatic temperature at fixed point of : 30° - 60°C for systems with radiant panelscomposed of 2 ball valves with thermometer and one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ 6mt delivery, 3 way thermostatic valve, alignment spacer, and ball valve screw-driver adjustable for eventual substitution of pump, safety thermostat manual reset for stopping pump in case of abnormalities and isolating shell.

* predisposed for insertion of by-pass valve for eventual over pump pressure (Art P.301.03).

E.621

Invertable relaunch assembly DN25, composed of 2 ball valves with thermometer and one way valve, high efficency adjustable circulation pump ´Modulex Hybrid´ 6mt delivery, alignment spacer and ball valve with screw-driver adjustment for eventual substitution of pump and isolation shell.

* For power up to 50 KW: predispoded for insertion of by-pass valve for eventual over pump pressure (Art. P.301.03).

E.630

Invertable relaunch module DN 32 composed of 2 ball valves with thermometer and integrated one way valve, high efficiency adjustable circulating pump ´Modulex Hybrid´ with 6mt delivery, ball valve for eventual substitution of pump and isolating shell. Suitable for power upto 125 KW - Connections: 11/4´M and 11/2´ with largening rings included.

E.631

Module bestaande uit 2 kogelkranen met verb. (Art. E.430.10), een mengventiel (Art. E.614.12) met parallel aanvoer- en retourkoppeling 1 1/2´ M. aan de boilerkant, circulatiepomp (Art. P.064), 2 kogelkranen (Art. E.608.10) met 2 thermometers, 1 controleventiel. Uitgangverloopstuk 1´ V. Ingang verb. 1´ M. Tussenafstand uitgangen 125 mm.

Dit model kan eveneens gecombineerd worden met een apparaat dat overdruk voorkomt (Art. E.615.10).

E.634

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.705

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.704

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.700

Adajacent manifold “FLUIDHUB” for thermal installations in varnished steel with axis on deviations of 125mm , suitable for relay groups DN 25 and DN 32. Equipped with connection nut (M8) for fixing brackets. Complete of isolating shell with axis 125mm.

Main connections diam : 11/2´M with flat seat axis of 125 mm. Connections on deviations diam: 11/2´F swivel or 1´F swivel.

E.600

Dubbele modulaire gelijkvlakkige verdeelleiding in Inox DN 40 roestvrijstaal met 2´ M. en V. wartelmoerverloopstukken.

Tussenafstand inlaten & uitlaten 125 mm.

G.122

Decoupling brass fitting for diverts on manifold

Aansluitingen: 3/4´ M. Eurokonus x 3/4´ V. Eurokonus.

G.083

Connection kit for low temperature manifolds (radiating system) and high temperature manifolds (radiators and towel dryers).

E.693

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.692

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.691

Stainless steel hydraulic compensator AISI 304 L flat seat complete with thermal isolating shell, automatic deareator with check valve and mud draining tap.

Recommended max flow capacity : 6mc/h Max pressure 10 bar : Max temp: 110°C

E.690

Stainless steel hydraulic compensator AISI 304 L complete with thermal isolating shell, automatic deareator with check valve and mud draining tap.

Recommended max flow capacity : 3mc/h Max pressure 10 bar : Max temp: 110°C

G.135

Brass fitting with thermometer pocket with F swivel nut.

Conn. M. thread with washer press nut O ring and F swivel nut with flat seat. Complete with washer.

G.093

Thermal isolationg shell thermoformed closed cell for mixing groups

G.098

Electrical wiring box for circulating pump and safety thermostat for mixing groups. (90x90x40)

Complete of three cable glands, connection terminals and warning light indicating the pump locking coming from the safety thermostat having found abnormal exceeding limit of the set temperature.

G.120

Temperatuurmeethulsverbinding in messing voor uitlaten van verdeelleidingen.

Aansluitingen: 3/4´ M. Eurokonus x 3/4´ V. Eurokonus.

E.612

Paar 2´ V. afsluitdoppen voor verdeelleidingen Art. E.600 (n. 2 G.150.20).

G.134

3-Delige excentriekkoppeling om de aansluiting met verdeelleidingen te vergemakkelijken. (Excentriciteit 16 mm).

G.132

Adjustable differential overpressure by-pass kit for to and return manifolds over-lapped by 1´, with hole distance from 200 to 300mm . Connections: 1´M x 1´M

E.428

Kogelkraan, volle doorlaat, met M. koppeling, temperatuurmeethuls en vleugelgreep. Vernikkelde messing.

V. Koppeling + M. temperatuurmeethuls - Max. druk 30 bar.

G.131

Adjustable intermediate by-pass kit between mixing group from in and out flow manifolds

With wheelbase from 170 to 220mm, cinnections from 1´M x 1´F

G.127

Dressed end piece M for manifolds complete of exhaust valve and drain tap. With axel-space from 200 to 300 mm.

E.619

Paar beugels voor bevestiging van verdeelleiding Art. E.600. aan de muur.

Gemaakt uit 2 kragen, zware uitvoering, aanpaspare veer, douwels en vastzettende vijzen.

G.125

M. Eindstuk voor verdeelleiding met 3/8´ V. uitlaat voor luchtafscheider & 1/2´ V. uitlaat voor afvoerkraan.

E.147

4 way thermostatic mixing valve, threaded and adjustable.

Control range. 30-60°C Indicated for temp. reduction of underfloor heating systems. Control adjustable with knob.

E.149

Thermostatic mixing valve for underfloor heating systems.

Körper aus gesandetem und verchromten Messing. Regelbereich: 20° - 50°C. Regelskala 1-5. Sehr klein, daher kann man den Mischer direkt vor den Verteilersammelleitungen einbauen, um die Temperatur der Fußbodenheizung zu senken.

E.613

Suction valve for “Multiflex” tank with pull lever and foot valve. In brass with 1 ”M connection

Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

E.610
