Aanzuig- en retourkoppelingen: diameter 8, 10, 13 of 3/8´. Lengte aanzuigslang: 2.200 mm. Met diameter 6 koppeling, klaar voor aanhechting van niveaumeter A.040.00.

Accurate analog meter.

Max temp: 110°C – 230Vac – 50Hz – With three adjustable speeds. Suitable for working with antifreeze max : 50%

Max temperature: 110° C - 230 Vac - 50 Hz - Compatible function with antifreeze max: at 50% Delivery max: 6 mt - Flow max.: 60lt/min. Connections 1´. - hight 130 - A=98 - B=165 Function: automatic in relation to the delivery requested in order to optimize electical use- constant pressure - proportional pressure

Max flow rate: m3 / h 3.3. Self-regulating. It satisfies all the needs of the circulator in a single product. Complete with gaskets and power cables. 230 Vac power supply. - 4 year warranty.

Equipped with stainless steel heat exchanger AISI 304 (Art S.009) 2 pumps in energy class ´A´ (Art P.064.6) 2 ball valves (Art E.465), 2 ball valves with thermometer (Art E.478) and 2 check valves (Art A.010.10) Max working temp. 99°C Max working pressure 15 bar.

Art. T.109.40 - Complete with joint for valves Art. E.140 and Art. E.141.

When the temp. of the panels is superior to that of the water in the boiler, the thermostat starts the pump the allows for temp exchange between the panels and the boiler. With clock visability of temp.of collector and boiler.Collector 0°-200°C Feed 230V exit conn. for pump to boiler 5A Dimensions 131x88x(H)27.2 Probes connectabile upto 100mt.

The thermostat SOLAR CONTROL is an electronic device built after many years of experience in the thermal control field by ANTARES. This device allows you to keep a precise control of the temperature deriving from the solar panels and to distribute the hot water into the tank. Through the sensors it will detect the temperature of the water supplied to the tank and it will compare it with the fluids in the solar panel. When the temperature of the panels is higher than the one from the tank, the differential thermostat starts the pump which allows the exchange of heat between panel and tank. To ensure a perfect exchange of temperature the device has a temperature differential “delta T” variable from 1 to 9 °C which is controlled by the handle on the front part of the thermostat. Temperature control : 30-80 °C. Adjustable range : 1-9°C Relay Outlet 10A 230V. Installation DIN bar (3 modules). Dimensions 53x90x58. Probes connected up to 100 mts. Complete with 2 switch-offs: pump for solar panels and pump for circuit integration.
